ADDITIONAL INFORMATION
More specs & information upon request:
Drawworks: Rig Tech RT-400B
Rated: 750 HP
Drum Grooving: 1-1/8”
Max. Capacity: 476,336 lbs
Max. Single line pull: 70,715 lbs
SN: RT-B-001-2005
Powered by: (1) each of (2) 540 HP, Caterpillar C-15 Engines Auxiliary Brake: Eaton
Model: 424WCB2
Mast:
Make IDS
Model: 4R-72-500
Height: 71’-6”
Rated: 500,000# hook load capacity
Substructure: IDS
Model: HR12-1.0
Height: 15’ with skid beams and rig mats
Clear Height: 14’ with skid beams and rig mats
Capacity: 800,000 lbs
Hydraulic Power Unit: (Top Drive)
Power: (1) each 540/630HP, C-15/C-18, Caterpillar Engine
Hyd. Pump: HPU TD PKG
Make: Sauer Danfoss
Model: 90R250 MA5A38B80
Mud Pumps:
Manufacturer: Gardner Denver
Model: PZ -9
Quantity: (2) two each
HP: 1000
Piston Stroke: 9”
Working Pressure: 5000 psi
Max. Liner Size: 7”
Min. Liner Size: 4”
Drive: Mechanical drive w / torque converters
Power: (2) two each Cat 3508, 900 HP engines
Особенности товара
| Quantity | 2 |
| Manufacturer | MD Cowan |
| Model | MD 525 |
| SKU | 70 |
| Location | Arkansas |
| Price | Contact For Details |
